·       2 mono and 4 stereo line input with 4 XLR microphone inputs

·       MAIN L/R ¼" jack output

·       TAPE IN stereo RCA jacks for connection to a CD or MP3 player

·       REC OUT stereo RCA jacks for connection to a recorder

·       ¼" Stereo headphone & Balanced ¼" control room out

·       3-Band channel equalizer providing ±15 dB (HF, LF) and ±12 dB (MF) per channel

·       Peak LED indicator to check on the signal input of each microphone channel

·       Individual channel and main level control

·       Gain (trim) level control with sensitivity markings for both micrphone and line inputs

·       Low Cut (HPF) switch @75Hz to eliminate background microphone rumble

·       AUX and EFX controls to adjust the level of the signal sent to the respective bus

·       PAN control (mono channel) to position the signal across the master left and right bus

·       BALANCE control (stereo channel) to adjust the level between left and right signals

·       Switchable Phantom power (+48V) switch for safe and easy connection of condenser microphones

·       Level control for headphone and control room connections
