D Link DGS 151028P PoE Switch 10GbE SFP Ports 193W PoE Budget Stackable
PKR 181,499.00
Up to 1x PKR 181,499.00 interest-free
Reference: 330188
Quantity
Share
Related
Technical Specifications
D Link DGS 151028P PoE Switch 10GbE SFP Ports 193W PoE Budget Stackable
Technical Characteristics
Product description
D-Link DGS1510-28P PoE Switch, 24 28 Port Fast Ethernet Gigabit Managed PoE+ SmartPro w/ 2 Gigabit SFP Ports & 2 10GbE SFP+ Ports 193W PoE Budget Stackable
Specifications
| Power | |
|---|---|
| Power consumption (typical) | 238.7 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Packaging data | |
| Package weight | 3995 g |
| Package depth | 511 mm |
| Package height | 91 mm |
| Package width | 348 mm |
| Manual | True |
| Data transmission | |
| Switching capacity | 92 Gbit/s |
| Jumbo frames support | True |
| MAC address table | 16000 entries |
| Store-and-forward | True |
| Forwarding rate | 68.45 Mpps |
| Packet buffer memory | 1.5 MB |
| Number of static routes | 512 |
| Network | |
| Auto-negotiation | True |
| Cable types supported | Cat5 |
| Cable types supported | Cat5e |
| MAC address auto-learning supported | True |
| Flow control support | True |
| Port mirroring | True |
| Link aggregation | True |
| Broadcast storm control | True |
| Full duplex | True |
| Auto MDI/MDI-X | True |
| Head-of-line (HOL) blocking | True |
| 10G support | True |
| Networking standards | IEEE 802.1D |
| Networking standards | IEEE 802.1p |
| Networking standards | IEEE 802.1s |
| Networking standards | IEEE 802.1w |
| Networking standards | IEEE 802.1x |
| Networking standards | IEEE 802.3 |
| Networking standards | IEEE 802.3ab |
| Networking standards | IEEE 802.3ae |
| Networking standards | IEEE 802.3u |
| Networking standards | IEEE 802.3x |
| VLAN support | True |
| Operational conditions | |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Heat dissipation | 813.967 BTU/h |
| Ports & interfaces | |
| SFP module slots quantity | 2 |
| SFP+ module slots quantity | 2 |
| Power connector | DC-in jack |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Design | |
| Certification | CE, FCC, C-Tick, VCCI, BSMI, CCC |
| Stackable | True |
| Rack mounting | True |
| Safety | cUL, CB |
| Number of fans | 2 fan(s) |
| Product colour | Black |
| LED indicators | Activity |
| LED indicators | Link |
| LED indicators | PoE |
| LED indicators | Power |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | True |
| Power over Ethernet (PoE) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 193 W |
| Security | |
| MAC address filtering | True |
| Static port security | True |
| Access Control List (ACL) | True |
| DHCP features | DHCP server |
| DHCP features | DHCP client |
| SSH/SSL support | True |
| IGMP snooping | True |
| Management features | |
| Switch layer | L3 |
| Quality of Service (QoS) support | True |
| Web-based management | True |
| System event log | True |
| Switch type | Managed |
| Multicast features | |
| Multicast support | True |
| Performance | |
| Noise level | 46.4 dB |
| Virtual stacking (units) | 32 |
| Physical stacking (units) | 6 |
| Technical details | |
| Shipping (inner) case height | 383 mm |
| Shipping (inner) case width | 296 mm |
| Shipping (inner) case length | 529 mm |
| Shipping (inner) case net weight | 9270 g |
| Quantity per shipping (inner) case | 3 pc(s) |
| Shipping (inner) case gross weight | 12885 g |
| Pallet gross weight (air) | 533900 g |
| Number of cartons per pallet (air) | 40 |
| Quantity per pallet (air) | 120 pc(s) |
| Pallet length | 1100 mm |
| Pallet width | 1200 mm |
| Pallet height (air) | 2050 mm |
| Pallet gross weight (sea) | 533900 g |
| Number of cartons per pallet (sea) | 40 |
| Quantity per pallet (sea) | 120 pc(s) |
| Pallet height (sea) | 2050 mm |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 250 mm |
| Height | 44 mm |
| Weight | 2540 g |
