Performance

Maximum Takeoff Weight

48.50 oz / 1375 g

Maximum Horizontal Speed

31.1 mph / 50 km/h (P-mode)

44.7 mph / 72 km/h (S-mode)

Maximum Flight Time

30 Minutes

Hovering Accuracy

±0.98' / 0.3 m Horizontal with Vision Positioning

±0.33' / 0.1 m Vertical with Vision Positioning

Flight Control System

GNSS Support

GPS, GLONASS

3D Object Detection

Operating Range

0.7 to 23.0' / 0.2 to 7.0 m

Minimum Object Size

7.9 x 7.9" / 20.0 x 20.0 cm

Required Object Reflectivity

>8%

Vision System

Vision System

Downward, Forward, Backward, Left, Right

Velocity Range

46 ft/s / 14 m/s at 6.6' / 2 m

Maximum Altitude

32' / 10 m

Operating Range

0.0 to 32.8' / 0.0 to 10.0 m

Obstacle Sensory Range

0.7 to 23.0' / 0.2 to 7.0 m

Forward Field of View

60° (Horizontal)

±27° (Vertical)

Downward Field of View

70° (Front to Back)

50° (Side to Side)

Backward Field of View

60° (Horizontal)

±27° (Vertical)

Measuring Frequency

Not Specified by Manufacturer

Operating Environment

Surface with Clear Patterns at >15 lux

Remote Controller / Transmitter

Operating Frequency

2.4 GHz (2.4 - 2.483)

5.8 GHz (5.725 - 5.825)

Maximum Operating Distance

22,966' / 7000.04 m at 2.4 G

22,966' / 7000.04 m at 5.8 G

Transmitter Power

26 dBm (2.4 G)

26 dBm (5.8 G)

Connectivity

Not Specified by Manufacturer

Output Power

Not Specified by Manufacturer

USB Output Power

Not Specified by Manufacturer

Battery Type

1 x Built-In

Battery Chemistry

Lithium-Ion Polymer (LiPo)

Battery Capacity

6000 mAh

Battery Configuration

Not Specified by Manufacturer

Built-In Display Size

5.5"

Display Resolution

1920 x 1080

Storage Temperature

Not Specified by Manufacturer

Operating Temperature

Not Specified by Manufacturer

Charging Temperature

Not Specified by Manufacturer

Camera

Sensor

1" CMOS

Effective Pixels

20 MP

Focal Length

8.8mm / 24mm (35mm Equivalent)

Lens Field of View

84°

Aperture

f/2.8 - 11

Minimum Focusing Distance

3.3' / 1.0 m

Photo ISO Range

100 - 6400 (Manual)

100 - 3200 (Auto)

Video ISO Range

100 - 6400 (Manual)

100 - 3200 (Auto)

Electronic Shutter Speed

8 - 1/8000 Second

Mechanical Shutter Speed

Not Specified by Manufacturer

Photo Resolution

3:2: 5472 x 3648

16:9: 5472 x 3078

4:3: 4864 x 3648

Photo Format

JPEG, DNG

Video Format

4096 x 2160p at 24/25/30 fps (100 Mb/s MOV via H.265)

3840 x 2160p at 24/25/30 fps (100 Mb/s MOV via H.265)

2720 x 1530p at 24/25/30 fps (100 Mb/s MOV via H.265)

1920 x 1080p at 24/25/30/48/50/60/120 fps (100 Mb/s MOV via H.265)

1280 x 720p at 24/25/30/48/50/60/120 fps (100 Mb/s MOV via H.264)

Broadcast Resolution

Not Specified by Manufacturer

Recording Media

Not Specified by Manufacturer

Photo Modes

Auto-Exposure Bracketing (AEB), Burst Shooting, Interval, Single Shot

Operating Temperature

Not Specified by Manufacturer

Gimbal

Number of Axes

3 (Pitch, Roll, Yaw)

Control Range

Pitch: -90 to 30°

Yaw: 0 to 15°

Angular Speed

Not Specified by Manufacturer

Flight Battery

Battery Chemistry

Lithium-Ion Polymer (LiPo)

Capacity

5870 mAh / 89.2 Wh

Battery Configuration

4 S / 17.4 V

Maximum Charging Power

160 W

Charger

Model

Not Specified by Manufacturer

AC Input Power

100 to 240 VAC, 50 / 60 Hz

DC Input Power

Not Specified by Manufacturer

Output Voltage

17.5 V, 5.7 A

Power Rating

100 W

General

Number of Rotors

4

Weight

48.50 oz / 1375 g (Including Propellers, Battery, Gimbal, Camera)
