Capacity

Cooling (kBtu/h)

 9.5~47.7

Cooling (Kw)

 2.8~14

Heating (Btu/h)

 10.9~54.6

Heating (kW )

 3.2~16

Electrical Parameters1

Electrical Parameters1

Power supply (Ph V Hz)

 1/220~230/50/60

Performance

Performance

Air flow (H) (m3/h)

 700~1800

Sound pressure level（H/M/L) [dB(A)]

 32/30/29

Sound power level（H/M/L) [dB(A)]

 46/44/43

Installation

External dimensions(W D H) (mm)

 570/570/260

Shipping dimensions(W D H) (mm)

 718/680/380

Refrigerant liquid pipe (mm)

6.35

Refrigerant gas pipe (mm)

9.52

Static Pressure(Standard) (Pa)

-

Static Pressure(Max.) (Pa)

-

Controller

Wired(S-standard)

 YR-E17(S)

Wired(O-optional)

-

Infrared(O-optional,S-standard)

 YR-HD(O)

Drain Pump

O-optional,S-standard

-

Panel

Model Name

 PB-700IB

External dimensions(W/D/H) (mm)

 700/700/60

Net/Shipping weight (kg)

 2.8/4.5

Electrical Parameters2

Electrical Parameters2

Power supply (Ph/V/Hz)

-

Rated power input (kW )

-

Rated current (A)

-
