General Parameters
- "Capacity (Ton)":4 Ton
- Refrigerant:R22
- Color:White
Capacity
- "Cooling Capacity KW":14
- "Cooling Capacity (BTU)":48000
- Heating Capacity (BTU):51200
- Air Circulation (m3/h):1800
- Rated Power input (KW) Cooling:4.94
- Rated Power Input (KW) Heating:5.17
- "Power Supply (Ph/V/Hz)":3/380-415/50
- EER/COP(W/W):2.83/2.90
Piping Connection
- Gas Side Dia (mm):19.05
- Liquid Side Dia (mm):9.52
- Max Pipe Length (m):50
- "Max Drop (m)":30
Dimensions
- Indoor Packing Dimension W/D/H:1355/856/380
- Outdoor Net Dimension W/D/H:960/340/1250
- Outdoor Packing Dimension W/D/H:1095/410/1400
- Panel Net Dimension W/D/H:-
- Panel Packing Dimension W/D/H:-
Weight
- Indoor Gross weight (Kg):53.8
- Indoor Net weight (Kg):52
- Outdoor Gross Weight (Kg):104.8
- Outdoor Net Weight (Kg):99
- Panel Gross Weignt (Kg):-
- Panel Net Weignt (Kg):
